Brand: Fujikura
Fujikura CT-30A Fiber Optic Cleaver
The CT30 cleavers set the standard for portability, reliability and ease of use. Available for either signle fiber or ribbon splicing (up to 12 fiber ribbons) applications.
The CT30A Cleavers are compatible with all AFL Telecommunications fusion splicers.
Designed for excellent portability, the CT30A is equally at home in a splicing van or in a bucket truck and is ideal for FTTx applications.
The 16-position blade yields 48,000 single-fiber cleaves, or 4,000 12-fiber ribbon cleaves before
requiring replacement, and the built-in scrap collector conveniently stores fiber shards until they can
be safely discarded.
Specification:
|
Applicable fibers |
Silica optical fiber |
|
Bare fiber diameter |
125mm |
|
Cleaving angle |
0.5 degrees with single fiber |
|
Blade life |
48,000 fibers (1,000 fibers x 3 height x 16 positions) |
|
Blade positions |
3 height and 16 rotating positions |
|
Dimensions |
102W x 82D x 46H (mm) with FC-02 and FDB-03 |
|
Weight |
210g with FC-02 and FDB-03 |
Applications:
Single fibers: 250um to 900um coating, 125um cladding
Fiber Handling System: AD-30A Adapter Plate
Cleave Length: (900um fiber) 10mm to 20mm, (250um fiber) 6mm to 20mm
Part No: S014080
Accessories
Replacement Blade for CT-30 Series Cleavers: S012828
FC-02 Fiber Collector: S014092
AD-30A Adapter Plate: S014096
AD-30B Adapter Plate: S014100
FDB-02 Fiber Collector Scrap Box: S014104
Variation:
|
Model |
Cladding diameter |
Fiber count |
Cleaving length |
Fiber placing |
|
CT-30 |
125mm |
Up to 12 |
10mm |
Fiber holder |
|
CT-30A |
125mm |
Single |
6 to 20mm |
Fiber plate (AD-30A) |
